Straight track G½.Length 115 mm (half standard length).
H0 | 1:87
Asymmetrical three-way turnout DWW15 without turnout mechanisms. First divergence to the left, second divergence to the right.Length 287.5 mm (= G1 + G¼), branch angle 15° each, branch radius 873.5 mm each, frog angle 10.8°.To adapt the length a 57.5 mm G¼ straight track element and spacers D12 and D4 are included.Suitable turnout mechanisms (2 pieces are required):40296 (electric turnout mechanism right)or 10030 (below baseboard mechanism).Please note the operating instructions!
Curved track R3.Radius 419.6 mm, arc angle 30°.12 pieces are needed to form a full circle.
Crossing K30.Length of tracks 119 mm (= DG1). Crossing angle 30°. The railroad lines that cross each other are not electrically isolated.Among other things they are suitable for forming double track connections with the 15° turnouts or double slip turnouts.
Turnout right hand Wr15, without turnout mechanism.Length 230 mm (standard length), branch angle 15°, branch radius 873.5 mm, frog angle 10.8°.An 8-mm spacer element (D8) is included for diagonal installation.Suitable turnout mechanisms: 40296, 40298 or 10030.
